Product Overview
Laser Cutting head RAYTOOLS / WSX / PRECITEC (optional)
Multiple Protection
3 pieces of protection lens, highly effective protection of collimating focus lens. 2-way optical water cooling, effectively extending
the continuous working time.
High-precision
The closed-loop stepping motor is adopted to effectively avoid step loss. The focusing speed is 100 m m / s and the repetition accuracy is 1 μ M. IP65 class dust-proof, patent protection mirror cover plate, dust-proof without dead angle.
Various Brands Of Laser Head Are Available
We can provide all high quality laser heads. All have been tested by us for a long time. Raytools/WSX/Porad all of them are our long-term part-ners.
Integral Steel Mold & Die-casting Technology
Monolithic cast aluminum beam, light weight, high strength, no deformation. Molded and framed by integral steel mold and die-casting technology, light cross-beam make equipment a high operation speed, improving pro-cessing efficiency and processing quality.
High Speed
The light crossbeam can ensure the machine have high moving speed and improve the pro-cessing efficiency.
More Efficient
The aluminum profile beam of the aerospace industry makes the equipment have efficient dynam-ic performance, greatly improving processing efficiency while ensur-ing processing quality.
Control System
Cypcut control system
The most professional control system for the fiber laser cutting machine
Fully functional, with all function that use on plate.
Cutting technique
Support offset tube center error in production to improve through holes cutting preci-sion；Support steel channels cutting;Support separation technique for corner cutting. Support auto loading/unloading pro-cess, cycle production and automatic tube feeding. Support all functions of FSCUT2000
Control performance
Open-loop control system, Friendess 5th generation motion control algorithms. Trajectory accuracy 0.02mm, positioning accuracy 0.001mm, repeatability 0.003mm. Access en-coder feedback in real time, to compare com
