Description
Standart Features
» PRO 80 are driven by hydraulic motor and gear system
» All machine body manufactured of St-52 special steel
» Rolls and shafts are made of special steel, with induction hardened and grinded
» Vertical and horizontal working possibility
» Guide roll adjustment manually to one direction
» Electrical protection aganist overloading
» Digital readout for displaying the position of lower rolls.
» Independence movement of the bottom rolls up and down hydraulically
» Portable control panel in order to control material from required locations with foot pedal
» In accordance with CE norms
Optional Accesories
» Special profile rolls for bending pipe, H, I, U, etc, type materials
» Hydraulic guide rolls for PRO 80 model in two directions
» Special mechanic guide rolls in order to facilitate angle bending
» Digital readout for displaying of the positions of the hydraulic guide rolls (for PRO 80)
» Spiral bending device
» NC Playback and NC graphic control system
» CNC graphic control system
» Electric motor according to required voltage and frequency
» Adjustable rotation speed
